Description
Supports up to 30A, 120V power distribution
Equipped with 10 NEMA 5-20R outlets for versatile power connections
Horizontal mounting to fit various rack configurations
12 ft cord for flexible installation
The unit is designed for reliable power distribution and includes rack mounting brackets and a user manual.
Description
It is a basic rack PDU with a 1U horizontal mounting design. It supports a maximum input current of 30A and operates at 120V. The PDU features 10 NEMA 5-20R outlets, providing ample connections for IT equipment. It includes a 12-foot power cord with a NEMA L5-30P plug. The unit is designed for reliable power distribution and includes rack mounting brackets and a user manual.
Specifications
Overview
| Lead time |
Usually in Stock |
Main
| Color |
Black |
| Product or Component Type |
PDU |
| PDU Type |
Basic |
| Cord length |
12 ft (3.7 m) |
| Number of cables |
1 |
| Provided Equipment |
User Manual
Rack Mounting brackets |
Complementary
| Input Voltage |
100 V
120 V |
| Height |
1.73 in (4.4 cm) |
| Width |
17.60 in (44.7 cm) |
| Output Voltage |
120 V |
| Depth |
2.24 in (5.7 cm) |
| Net Weight |
5.5 lb(US) (2.5 kg) |
| Mounting Location |
Front
Rear |
| Mounting preference |
No preference |
| Input Plug Type |
NEMA L5-30P |
| Mounting Mode |
Rack-mounted |
| Rack units |
1U |
| Mounting position |
Horizontal |
| Line Rated Current |
24 A |
| Permissible voltage |
90…132 V |
| Max line current |
24 A |
| Input current limits |
30 A |
| Load Capacity |
2880 VA |
| Input Frequency |
50/60 Hz |
| Outlet type and quantity |
10 NEMA 5-20R |
Environment
| Product Certifications |
cUL Listed
UL Listed |
| Standards |
UL 60950 |
| Ambient air temperature for operation |
5…113 °F (-15…45 °C) |
| Relative Humidity |
0…95 % |
| Operating altitude |
0…10000 ft |
| Ambient Air Temperature for Storage |
-13…149 °F (-25…65 °C) |
| Storage Relative Humidity |
0…95 % |
| Storage altitude |
0…50000 ft (0.0000000000…15240.0000000000 m) |
Ordering and shipping details
| Category |
11309-APC RESALE PRODUCTS |
| Discount Schedule |
APC1 |
| GTIN |
731304192930 |
| Returnability |
No |
| Country of origin |
IN |
Packing Units
| Unit Type of Package 1 |
PCE |
| Number of Units in Package 1 |
1 |
| Package 1 Height |
5.98 in (15.2 cm) |
| Package 1 Width |
6.97 in (17.7 cm) |
| Package 1 Length |
19.13 in (48.6 cm) |
| Package 1 Weight |
8.02 lb(US) (3.64 kg) |
Contractual warranty
| Warranty |
2 years repair or replace |
